Product Description

Welding Wire
\Grade: ER308;ER308L;ER308LSI;ER308LHSI;ER309;ER309L;ER309LSI;ER309LHSI; ER316;ER316L;ER316LSI;ER316LHSI;ER321;ER410;etc
: ,(SAW),(TIG),(MIG).								Application: With steady chemical compositions,it can be used in welding and manufacturing semi-finished of SAW,TIG,MIG wire,etc.
	Chemical compsition %												mm
TYPE	C	Si	Mn	P	S	Ni	Cr	Mo	Cu	Others	Mpa	EL	mm
ER308	0.05	0.25	1.70-2.50	0.025	0.015	9.55-11.00	19.50-22.0	0.3	0.75	0.05	700-950	10-30%	0.80-6.00
ER308L	0.025	0.25	1.70-2.50	0.025	0.015	9.55-11.00	19.50-22.0	≤ 0.30	≤ 0.75	0.04	700-950	10-30%	0.80-6.00
ER308LSI	0.025	0.45-0.65	1.70-2.50	0.025	0.02	9.60-11.00	19.50-22.0	≤ 0.30	≤ 0.75	0.04	1200-1700	10-30%	0.80-6.00
ER308LHSI	0.025	0.45-0.65	1.70-2.50	0.025	0.02	9.60-11.00	19.50-22.0	≤ 0.30	≤ 0.75	0.04	1200-1700	10-30%	0.80-6.00
ER309	0.08	0.25	1.70-2.50	0.025	0.02	12.50-14.00	23.00-25.00	0.75	0.3	0.08	700-950	10-30%	0.80-6.00
ER309L	0.02	0.25	1.70-2.50	0.025	0.02	12.50-14.00	23.00-25.00	0.75	0.3	0.08	700-950	10-30%	0.80-6.00
ER309LSI	0.025	0.75-1.00	1.70-2.50	0.025	0.02	12.50-14.00	23.00-25.00	0.75	0.3	0.08	1200-1700	10-30%	0.80-6.00
ER309LHSI	0.025	0.55-0.65	1.70-2.50	0.025	0.02	12.50-14.00	23.00-25.00	0.75	0.3	0.08	1200-1700	10-30%	0.80-6.00
ER316	0.05	0.25	1.70-2.50	0.025	0.015	11.50-14.00	18.00-20.00	2.00-3.00	0.3	0.05	700-950	10-30%	0.80-6.00
ER316L	0.025	0.25	1.70-2.50	0.025	0.015	11.50-14.00	18.00-20.00	2.00-3.00	0.3	0.05	700-950	10-30%	0.80-6.00
ER316LSI	0.025	0.75-1.00	1.70-2.50	0.025	0.015	11.50-14.00	18.00-20.00	2.00-3.00	0.3	0.05	1200-1700	10-30%	0.80-6.00
ER316LHSI	0.025	0.45-0.65	1.70-2.50	0.025	0.015	11.50-14.00	18.00-20.00	2.00-3.00	0.3	0.05	1200-1700	10-30%	0.80-6.00
ER307	0.05-0.12	0.25	3.30-4.75	0.03	0.015	8.00-10.70	19.50-22.00	0.50-1.50	0.3	0.05	700-950	10-30%	0.80-6.00
ER307SI	0.05-0.12	0.25	3.30-4.75	0.03	0.015	8.00-10.70	19.50-22.00	0.50-1.50	0.3	0.05	700-950	10-30%	0.80-6.00
ER310	0.08-0.14	0.20-0.45	1.70-2.00	0.025	0.015	20.50-22.50	25.00-27.00	0.5	0.3	0.05	700-950	10-30%	0.80-6.00
ER321	0.05	0.25	1.50-2.50	0.03	0.015	9.50-10.50	19.00-20.50	0.5	0.3	0.01	700-950	10-30%	0.80-6.00
ER347	0.05	0.25	1.50-2.50	0.03	0.015	9.30-10.50	19.00-20.50	0.5	0.3	0.01	700-950	10-30%	0.80-6.00
ER385	0.025	0.5	1.00-2.50	0.02	0.01	24.00-26.00	19.00-21.50	0.5	0.3	0.01	700-950	10-30%	0.80-6.00
ER410	0.08-0.12	0.5	0.60	0.025	0.015	0.5	12.50-13.50	0.5	0.3	0.05	500-700	10-20%	0.80-6.00
ER430	0.06	0.5	0.60	0.03	0.015	0.5	16.00-17.00	0.5	0.4	0.03	500-700	10-20%	0.80-6.00
ER2209	0.03	0.9	0.50-2.00	0.03	0.015	7.50-9.50	21.50-23.5	2.5-3.5	0.4	0.08-0.20	700-950	10-30%	0.80-6.00
