Stainless Steel Wire
Dia: 0.2-3.0mm
Materail: 304, 316, 304L, 316L, etc
Package: Plastic reel, steel wire, no, etc
T/s: Soft, hard, etc Advantage: Our range of Wire made of Stainless Steel are not only known for their variety but are also known for their good quality, long life and very reasonable prices. Quality and service is our first priority, we effectively use technically advanced machinery equipment and the expertise of our work to deliver our stainless steel wired products.
| Chemical composition table |
| | C | Si | Mn | P | S | Ni | Cr | Mo | Cu |
| 304 | <0.08 | <1.0 | <2.0 | <0.035 | <0.03 | 8-10 | 17-19 | - | - |
| 304L | <0.03 | <1.0 | <2.0 | <0.04 | <0.03 | 9-13 | 18-20 | - | - |
| 304HC | <0.06 | <1.0 | 1.2-1.8 | <0.035 | <0.03 | 8-11 | 17-19 | - | 2-3 |
| 316 | <0.08 | <1.0 | <2.0 | <0.04 | <0.03 | 10-14 | 16-18 | 2-3 | - |
| 316L | <0.03 | <1.0 | <2.0 | <0.04 | <0.03 | 12-15 | 16-18 | 2-3 | - |
| 310S | <0.08 | <1.5 | <2.0 | <0.04 | <0.03 | 19-22 | 24-26 | - | - |
| 321 | <0.08 | <1.0 | <2.0 | <0.045 | <0.03 | 9-13 | 17-19 | - | - |
| 301 | <015 | <1.0 | <2.0 | <0.04 | <0.03 | >7 | 16-18 | - | - |
| 302 | <0.15 | <1.0 | <2.0 | <0.04 | <0.03 | >8 | 17- | - | - |
| Stainless steel wire size tolerance |
| Wire diameter (mm) | Tolerance (mm) | Maximum deviation (mm) |
| 0.-0.299 | ±0.005 | 0.005 |
| 0.300-0.310 | ±0.006 | 0.006 |
| 0.320-0.499 | ±0.006 | 0.006 |
| 0.500-0.599 | ±0.006 | 0.006 |
| 0.600-0.799 | ±0.008 | 0.008 |
| 0.800-0.999 | ±0.008 | 0.008 |
| 1.00-1.20 | ±0.009 | 0.009 |
| 1.20-1.40 | ±0.009 | 0.009 |
| 1.40-1.60 | ±0.010 | 0.010 |
| 1.60-1.80 | ±0.010 | 0.010 |
| 1.80-2.00 | ±0.010 | 0.010 |
| 2.00-2.50 | ±0.012 | 0.012 |
| 2.50-3.00 | ±0.015 | 0.015 |
| 3.00-4.00 | ±0.020 | 0.020 |
| 4.00-5.00 | ±0.020 | 0.020 |
| Welding Wire |
| \Grade: ER308;ER308L;ER308LSI;ER308LHSI;ER309;ER309L;ER309LSI;ER309LHSI; ER316;ER316L;ER316LSI;ER316LHSI;ER321;ER410;etc |
| : ,(SAW),(TIG),(MIG). | Application: With steady chemical compositions,it can be used in welding and manufacturing semi-finished of SAW,TIG,MIG wire,etc. |
| | Chemical compsition % | | mm |
| TYPE | C | Si | Mn | P | S | Ni | Cr | Mo | Cu | Others | Mpa | EL |
| ER308 | 0.05 | 0.25 | 1.70-2.50 | 0.025 | 0.015 | 9.55-11.00 | 19.50-22.0 | 0.3 | 0.75 | 0.05 | 700-950 | 10-30% | 0.80-6.00 |
| ER308L | 0.025 | 0.25 | 1.70-2.50 | 0.025 | 0.015 | 9.55-11.00 | 19.50-22.0 | ≤ 0.30 | ≤ 0.75 | 0.04 | 700-950 | 10-30% | 0.80-6.00 |
| ER308LSI | 0.025 | 0.45-0.65 | 1.70-2.50 | 0.025 | 0.02 | 9.60-11.00 | 19.50-22.0 | ≤ 0.30 | ≤ 0.75 | 0.04 | 1200-1700 | 10-30% | 0.80-6.00 |
| ER308LHSI | 0.025 | 0.45-0.65 | 1.70-2.50 | 0.025 | 0.02 | 9.60-11.00 | 19.50-22.0 | ≤ 0.30 | ≤ 0.75 | 0.04 | 1200-1700 | 10-30% | 0.80-6.00 |
| ER309 | 0.08 | 0.25 | 1.70-2.50 | 0.025 | 0.02 | 12.50-14.00 | 23.00-25.00 | 0.75 | 0.3 | 0.08 | 700-950 | 10-30% | 0.80-6.00 |
| ER309L | 0.02 | 0.25 | 1.70-2.50 | 0.025 | 0.02 | 12.50-14.00 | 23.00-25.00 | 0.75 | 0.3 | 0.08 | 700-950 | 10-30% | 0.80-6.00 |
| ER309LSI | 0.025 | 0.75-1.00 | 1.70-2.50 | 0.025 | 0.02 | 12.50-14.00 | 23.00-25.00 | 0.75 | 0.3 | 0.08 | 1200-1700 | 10-30% | 0.80-6.00 |
| ER309LHSI | 0.025 | 0.55-0.65 | 1.70-2.50 | 0.025 | 0.02 | 12.50-14.00 | 23.00-25.00 | 0.75 | 0.3 | 0.08 | 1200-1700 | 10-30% | 0.80-6.00 |
| ER316 | 0.05 | 0.25 | 1.70-2.50 | 0.025 | 0.015 | 11.50-14.00 | 18.00-20.00 | 2.00-3.00 | 0.3 | 0.05 | 700-950 | 10-30% | 0.80-6.00 |
| ER316L | 0.025 | 0.25 | 1.70-2.50 | 0.025 | 0.015 | 11.50-14.00 | 18.00-20.00 | 2.00-3.00 | 0.3 | 0.05 | 700-950 | 10-30% | 0.80-6.00 |
| ER316LSI | 0.025 | 0.75-1.00 | 1.70-2.50 | 0.025 | 0.015 | 11.50-14.00 | 18.00-20.00 | 2.00-3.00 | 0.3 | 0.05 | 1200-1700 | 10-30% | 0.80-6.00 |
| ER316LHSI | 0.025 | 0.45-0.65 | 1.70-2.50 | 0.025 | 0.015 | 11.50-14.00 | 18.00-20.00 | 2.00-3.00 | 0.3 | 0.05 | 1200-1700 | 10-30% | 0.80-6.00 |
| ER307 | 0.05-0.12 | 0.25 | 3.30-4.75 | 0.03 | 0.015 | 8.00-10.70 | 19.50-22.00 | 0.50-1.50 | 0.3 | 0.05 | 700-950 | 10-30% | 0.80-6.00 |
| ER307SI | 0.05-0.12 | 0.25 | 3.30-4.75 | 0.03 | 0.015 | 8.00-10.70 | 19.50-22.00 | 0.50-1.50 | 0.3 | 0.05 | 700-950 | 10-30% | 0.80-6.00 |
| ER310 | 0.08-0.14 | 0.20-0.45 | 1.70-2.00 | 0.025 | 0.015 | 20.50-22.50 | 25.00-27.00 | 0.5 | 0.3 | 0.05 | 700-950 | 10-30% | 0.80-6.00 |
| ER321 | 0.05 | 0.25 | 1.50-2.50 | 0.03 | 0.015 | 9.50-10.50 | 19.00-20.50 | 0.5 | 0.3 | 0.01 | 700-950 | 10-30% | 0.80-6.00 |
| ER347 | 0.05 | 0.25 | 1.50-2.50 | 0.03 | 0.015 | 9.30-10.50 | 19.00-20.50 | 0.5 | 0.3 | 0.01 | 700-950 | 10-30% | 0.80-6.00 |
| ER385 | 0.025 | 0.5 | 1.00-2.50 | 0.02 | 0.01 | 24.00-26.00 | 19.00-21.50 | 0.5 | 0.3 | 0.01 | 700-950 | 10-30% | 0.80-6.00 |
| ER410 | 0.08-0.12 | 0.5 | 0.60 | 0.025 | 0.015 | 0.5 | 12.50-13.50 | 0.5 | 0.3 | 0.05 | 500-700 | 10-20% | 0.80-6.00 |
| ER430 | 0.06 | 0.5 | 0.60 | 0.03 | 0.015 | 0.5 | 16.00-17.00 | 0.5 | 0.4 | 0.03 | 500-700 | 10-20% | 0.80-6.00 |
| ER2209 | 0.03 | 0.9 | 0.50-2.00 | 0.03 | 0.015 | 7.50-9.50 | 21.50-23.5 | 2.5-3.5 | 0.4 | 0.08-0.20 | 700-950 | 10-30% | 0.80-6.00 |
